Motor series For Coil Pipes with High Pressure and Fresh Air Conditioner

一、Description

1. series of this kind of motors has been designed and manufactured by

us,according to need of Chinese Academe of Architecture Science.It matches specially to thin fan cupboard,Fresh Air Conditioner and Coli Pipes with High Pressure & Large Airflow.

2. It has the advantages of small vibration,low noise,low tempeture-rise,three

layers ofRPM,running smoothly and rapidly.

3. It can matches the impellers,diameter of 140mm,250mm,300mm,airflow of 1000 m³

/h,pressure of 250Pa.

二、Dimensions

三、Designation And Drawing of wiring

五、Specifications and Mounting Sizes

Model	A	B	C	Rated power（W）	Operating load speed（±r/min）
Model	A	B	C	Rated power（W）	Hi	Me	Lo
YDKJ-6	377	0	55	125	850	750	600
YDKJ-6	377	0	55	150	850	750	600
YDKJ-6	377	0	55	180	850	750	600
YDKJ-6	565	188.5	55	200	850	750	600
YDKJ-6	565	188.5	55	250	900	750	600
YDKJ-6	565	188.5	55	300	900	750	600
YDKJ-6	565	188.5	55	370	900	750	600
YDKJ-4	428	0	50	200	1050	950	850
YDKJ-4	650	231	50	350	1050	950	850
YDKJ-4	650	231	50	400	1050	950	850
YDKJ-4	650	231	50	500	1050	950	850

Model	Operating load power（W）	Noise [Db(A)]	Cap UF/V	Input（A）
YDKJ-6	280	≤47	6.0	1.2
YDKJ-6	290	≤47	10	1.4
YDKJ-6	350	≤47	12	1.5
YDKJ-6	385	≤47	12	1.8
YDKJ-6	480	≤47	12	1.9
YDKJ-6	575	≤47	20	2.3
YDKJ-6	708	≤47	20	2.8
YDKJ-4	409	≤58	12	2.0
YDKJ-4	681	≤58	20	3.2
YDKJ-4	781	≤58	20	3.6
YDKJ-4	798	≤58	20	3.9

六、Note

1. Wiring must be according to the Drawing of wiring.

2. All of the air-conditioning motors is tested on 220V 50Hz.The insulation class is E.

3. We can produce series of the motors as per your application,which has varies voltage,frequency,outward size,assembling size,power and so on.If you have any Questions,plese contact the deparment of technique in Huate.
